Description
GetFace IP - I/O module
FEATURES:
- Allows extending the number of inputs and outputs of
the GetFace IP Basic Unit. It includes:
- 2 relays 30V/1A AC/DC (NO/NC contacts)
- 2 passive/active inputs (-30VDC..30VDC)
0=abierto o VIN1>1.5VDC
1=cerrado o VIN1<1.5VDC
- 4 input (green) / output (red) status LED indicators
- Input of Tamper switch (ZVP-ACTAM)
- The module integrates two interchangeable GetFace
bus connectors for connections to/from GetFace IP
Basic Unit or other modules. If this module is the last
one on the bus, one of the connectors remains
unconnected.
- GetFace bus cable included (80mm long).
- Please refer to the GetFace IP manual for
configuration.
- Conformity with the CE directives.
