Description
GetFace IP - Vigik module
FEATURES:
- Allows connecting a Vigik contactless card reader to the
GetFace IP Basic Unit.
- Number of users supported: 1500 in local mode.
- Auxiliary Power supply needed: 12-30VDC, 500mA or 12-
24VAC, 50Hz, 6A.
- Maximum consumption: 200mA.
- Reader frequency: 13.56MHz.
- Operation temperature: -20 to +55ºC.
- Controller dimensions: 70x70x19mm.
- Please refer to the frame assembly instructions (ignore the
GetFace bus connection) and the GetFace IP manual for
installation.
- Conformity with the CE directives.
