Capacitive push button Touch-MyDesign - 8 Buttons & Thermostat. Aluminium frame - White

Touch-MyDesign Plus is a KNX switch with capacitive buttons that satisfies the design requirements of any building thanks to its total customization: Everyone can create unique compositions, which could include images, icons, texts or logos, as well as decide how to install it (portrait or landscape). This customization is printed on a high-strength tempered glass, with an anodized aluminium frame to finish off the authorâ€™s work. Eight buttons are the available formats, so that pairs or individual buttons can be used as personalized controls with LED indicators. TMD has 5 LEDS that can be used as additional buttons to assign direct functions. TMD also includes thermostat function, internal temperature probe and two analog/digital inputs.

CHARACTERISTICS

Completely customized image for printout glass, through web application.
8 main touch areas.
5 auxiliary touch areas.
2 analog/digital inputs.
No power supply different from the bus needed.
Thermostat.
Temperature sensor.
Status LED indicators.
Custom LED luminosity.
KNX BCU integrated.
Magnetic fit with security mechanism to avoid accidental extraction.
Metallic stand included.
Complete data saving in case of power failure.
CE directives compliant.
